2024 STEELMASTER SM-HEPM200 200Ton Sliding Head
Features
Title | 2024 STEELMASTER SM-HEPM200 200Ton Sliding Head |
Type | Engineering - Fabrication |
Sub Type | Presses |
Make | STEELMASTER |
Model | SM-HEPM200 |
Series | 200Ton Sliding Head |
Year | 2024 |
Sale Price | 17850 $19,635 |
Listing Type | New |
Stock Number | 27-0283 |
RefCode | TA961868 |
Description
Description.
NEW Fixed & Sliding Head Model All in One! For your toughest shop pressing needs, these Motorized Hydraulic Presses do it all.
Simple Pendant control up & down control, built-in pressure gauge provides exact pressure readings.
Fully adjustable fixed or left & right sliding adjustment of the hydraulic ram - offering full flexibility when offset bending required.
Quick lock power assist table raise and lowering of the bed, which can be adjusted multiple locations along its massive steel frame.
The operator can chose operate the ram in automatic (motorized) or manual (hand pump) for even more control.
Features.
200 ton force.
fixed central position or slide left or right.
offering more flexibility to your pressing applications
twin speed control with manual adjustment
for the removal and press-fit of bearings and bushings
extremely torsion proof steel welded frame
hydraulic pressure gauge fitted
quick fit work plate with vee blocks supplied.
lifting chains included
wide frame models available up to 1500mm wide
Technical Snapshot
capacity - 200Ton
frame width distance - 1500mm
stroke length - 400mm
max. pressure 244 bar
cylinder fixed & sliding
working speed 3.6 (1.8)mm / sec
approach speed 3.6 (6.6)mm / sec
return speed 5.2 (8.8)mm / sec
oil tank capacity 30 litres
power 7.5kw / 415Volt
dimensions - 1930mm x 1118mm x 2235mm x 2200kg
Optinal Guards
Front Swing Out Door Guards & Rear Guards Available - Please quote SKU - 27+0014
Factory fitted guards only applies to pricing
If you cant find what you're looking for call us on or look online www.steelmastermachinery.com.au
Servicing the Industrial Metalworking Industry since 1997
We have many more items available than listed here.
Asset offer a wide variety of metalworking machinery, spare parts and accessories to suit our range
Industries service range from Engineering, Metalworking Fabrication & Sheetmetal Shops Australia Wide.
Also offering national delivery on metalworking bandsaw & cold saw blades, Punch & Shear Tooling, Pressbrake Tooling, Industrial Conveyors and much more.
We can also offer experienced service technicians in house or onsite to assist Please contact us for further information.
Visit our website, or call us with your requirements
Tell us what you are after, chances are we have it already.
For More information on our machine, go to or contact a Steelmaster industrial Rep
MAKE YOUR NEXT PURCHASE AN "ASSET" TO YOUR COMPANY!
Please contact us for more information.
