2024 STEELMASTER SM-FU-500S-20 - HEAVY DUTY BED MILL 2000mm x 500mm Table
Features
Title | 2024 STEELMASTER SM-FU-500S-20 - HEAVY DUTY BED MILL 2000mm x 500mm Table |
Type | Engineering - Fabrication |
Sub Type | Milling Machines |
Make | STEELMASTER |
Model | SM-FU-500S-20 - HEAVY DUTY BED MILL |
Series | 2000mm x 500mm Table |
Year | 2024 |
Sale Price | 70850 $77,935 |
Listing Type | New |
Stock Number | 13-0220 |
RefCode | TA963664 |
Description
Description.
Heavy duty universal mill offering precision servo operated ball screw drive operating in X, Y & Z axis. Combining and extra large working area and large travels to suit, we are confident this will cover your milling applications. Quality build and features this Mill offers muscle combined with built-in durability for years of service. Turcite - B coated guides, X axis dovetail guides, spindle brakes, pre loaded ball screws with zero backlash to name a few features. This is the machine to have for years of accurate, trouble-free operation.
We also offer these with SIEMENS CNC Controllers.
Features.
infinitely variable feed speeds controlled via DC servo.
rapid feed on all 3 axis
heavy duty ribbed machine frame ensures maximum rigidity
rigid, torsion proof powered overarm
universal by-rotative milling head
safety interlocks to prevent simultaneous use of feed and table clamping
ergonomic pendant type control console for easy access
electric spindle brake
automatic lubrication system
suds pump and coolant system
LED work light
multifunction 3 axis DRO
splash guard / chip tray
tool kit supplied
operation manual
we also offer these with SIEMENS CNC Controllers
Technical Data - Snap Shot
table size - 2000mm x 500mm
table travel 1500mm x 500mm
distance between T-slot 80mm
T-slot size 18mm (5 off)
X / Y / Z travel - 1500mm/ 500mm / 700mm
head type universal
table load 1800Kg
universal head spindle fixture - ISO / INT-50
operating speeds - 30 ~ 2050 (27)
distance spindle to table 25mm ~ 525mm
distance spindle to column 55mm ~ 755mm
ram traverse travel - 600mm
motor capacity - 7.5Kw x 415Volt
shipping dimensions - 2800mm x 2260mm x 2200mm
approx weight: 5000kg
Includes
3 Axis digital readout system
safety cutter guard
swarf tray
coolant system
LED lamp
